https://youtu.be/kvHDBd5jMKM The E-ONE 50’ Boom aerial is designed for aerial firefighting and consist of: • The aerial consists of three welded extruded aluminum telescopic boom sections operating from -10 degrees to 85 degrees and is designed to provide continuous egress for firefighters and civilians from an elevated position to the ground. The aerial device has…
https://youtu.be/JqQ5f0GhQ8g A polypropylene foam tank with the capacity of 750 Gallons, is installed on the Fire Apparatus. The foam tank maybe filled from fill tower on top of the vehicle or by using FOAM FILL port on the left side of the vehicle.
https://youtu.be/bcGSQw8YSd0 Rated load capacity label is installed next to the master control panel. At the condition of water tower operation 1000-1500 GPM water stream, for the elevation angel from -10 degrees to 45 degrees no one is allowed to stand at the tip but for the elevation angel from 46 to 85 degrees, one people…
https://youtu.be/HoaCmRH_Iy8 The main components of the Rosenbauer fire truck include: the chassis, engine, gearbox, water and foam tanks, water pump and connections, water and foam inlets and outlets, cabin, CAFS compressed air bottles, roof turret and light mast.
https://youtu.be/tnP0HmUwFiE Water tank is a polypropylene plastic tank whit the capacity of 1585 Gallons. The capacity of foam compound tank is 1057 Gallons. Maximum permitted tanks overpressure is 0.3 bar (4.3 psi).
https://youtu.be/SDTq-ijOt08 In this fire engine, R600 Model pump is applied and the maximum output is up to 7000 liter per minute at 10 bar. Closing pressure is 16 bar and maximum pump speed is 2540 rpm. The R pump types are twin-stage normal pressure pumps. The water pump is driven via the PTO of the…
